特点:
1.本产品是一个简单快速的温度测试工具,
2.操作简单:
|
Feature : 1.
2.easy to operate u attach close to the detected objects minimized wiring loss u Data transfer can be done right after take out from the oven, No cool down press is needed. u One key data access function .speed up data gathering. 3.High Accuracy : u Windows platform ensures the user –friendly interface and highly software compatibility. u PROFILE software simulates system. u Take down survey temperature place, to set the temperature can be consult basis. u It can to set temperature curve and time assay. |
规格:
量测点Channels |
6Channels (GAM-200-6) |
4 Channels (GAM-200-4) |
分辨率Resolution |
0.1℃ |
|
重复精度Accuracy |
±1℃ |
|
取样速率 Sampling Period |
0.1-25秒 |
|
温度量测范围Range |
最高300℃ |
|
电池Power Source |
9.6V |
|
传输方式 Record Output |
RS232 |
|
尺寸Dimensions |
内盒Inside Size:175*105*14mm 外盒Outside Size:210*120*23mm 内PC板夹持范围PCB Clip Range:25-190mm |
|
重量Weight |
内盒Inside Size:0.5kg 外盒Outside Size0.6kg 主机支撑架Rack of Mainframe :0.65kg PC板支撑架Rack of PCB :0.4kg 总重Total: 6.5kg |
